MARKET LEADING PERFORMANCE
The VersaDrive V125T offers heavy duty, portable drilling up to 125mm diameter. An all day broaching capacity combines with powerful tapping capability up to M32 for both through & blind holes thanks to a powerful forward/reverse, variable speed, multi-geared Eibenstock motor.
Advanced British electromagnets also provide enhanced magnet hold for exceptional safety and stability. Supplied with a coolant fed arbor.
In addition to standard through-hole tapping, the V125T can also be used with the VersaDrive blind hole tapping system up to M30 diameter.
Supplied with handles, restraint strap, heavy duty metal sliding guard system, MT3 Morse Taper broaching arbor, VersaDrive Rapid lock adapter, heavy duty, waterproof, shock-resistant site case and gravity fed coolant system.
Technical Specification
CUTTER SIZE RANGE | 12 - 125mm TCT |
MAX CUTTER CAPACITY | 125mm TCT |
TWIST DRILL CAPACITY | 32mm |
MAX TAP CAPACITY | M32 |
MAX COUNTERSINKING | 65mm |
LENGTH | 345mm |
WIDTH (Inc Handles) | 240mm |
HEIGHT (Min-Max) | 470 - 750mm |
STROKE | 280mm |
WEIGHT | 25 kg |
MAGNET (L X W) | 220 x 115mm |
MAGNETIC ADHESION | 2200 kgs |
MOTOR POWER | 1800w |
TOTAL POWER | 1900w |
SPEED RPM (No Load) | 60-140 / 100-220 / |
140-310 / 210-490 | |
SPINDLE | MT3 |
ARBOR | 19,05 mm (¾€) Weldon |
TAKES CHUCK | Yes |
COOLANT SYSTEM | Gravity Oil Fed |
WARRANTY | 2 Year |
